MediaTek MT8768

    Legacy 4G IoT SoC for mainstream, always-connected platforms. Featuring a power-efficient octa-core CPU and integrated GPU, plus integrated ISP with dual-camera support. FHD video encoding and decoding engines enable power-efficient video recording and multimedia playback.

    Wi-Fi, BT, global 4G LTE with dual SIM, and GNSS options provides diverse wireless connectivity choices for product designers.

    Platform Highlights

    • Octa-core CPU
    • Power-efficient GPU
    • Flexible memory options
    • Integrated ISP with dual-camera support
    • FHD60 display
    • FHD video encoding & decoding engine
    • Global LTE with dual SIM, dual standby
    • GNSS

    Specifications

    Process

    12nm

    CPU

    8x A53
    2.0GHz + 1.5GHz

    GPU

    IMG GE8320@650MHz

    APU

    N/A

    Memory

    1xLPDDR3 933MHz, up to 4GB
    2xLPDDR4x1600MHz, up to 6GB

    Camera

    21MP @ 30fps
    dual cam

    Video Decode

    1080P @ 30 fps, H.264/H.265

    Video Encode

    1080P @ 30 fps, H.264

    Display

    FHD 1920x1200 60fps

    Modem

    LTE Cat-4 / Cat-7
    L+W/L+L DSDS

    Connectivity

    MT6631: WiFi-5 1x1 + BT5.0
    +GPS+Glonass+Beidou+Galileo
