MediaTek MT8915

    MediaTek MT81950 is a high-end smart display SoC with powerful NPU. It's octa-core CPU provides superb performance with multitasking app capabilities, including 3D accelerated applications thanks to its impressive 5-core GPU.

    With advanced multimedia capabilities and impressive power efficiency from the 6nm chip design, it is ideal for wide-ranging applications including smart homes, conference rooms, reception areas, advertising, educational settings, large-screen presentations, cinematic uses, and other home, business or commercial applications.

    Platform Highlights

    • Highly efficient 6nm chip design
    • Octa-core CPU with 4x Arm Cortex-A78
    • 4.8 TOPS NPU ready for AI-display
    • Up to 16GB of quad-channel memory
    • High-end Penta-core GPU
    • Dual 4K display and HEVC enc/dec
    • Dedicated audio DSP
    • High resolution camera support
    • Dual-band Wi-Fi 6
    • Flexible I/O and display inputs
    • Android TV, Yocto Linux, Ubuntu OS supported

    Specifications

    CPU

    Processors

    • 4X Arm Cortex-A78 @ 2.2 GHz
    • 4X Arm Cortex-A55 @ 2.0 GHz

    Memory

    Speed/Type

    • Up to 16GB, quad-channel LPDDR4X @ 4266Mbps

    AI

    Type

    • Integrated multi-core NPU
    • 4.8 TOPS

    Audio

    DSP

    • HiFi 4

    GPU

    Type

    • Arm Mali-G57 MC5 @ 880MHz

    Display

    Resolution

    • 4K60 output
    • HDMI 2.1 input

    Video

    Encoding

    • 4K60, H.265/H.264

    Decoding

    •  4K90, AV1/VP9/HEVC/H.264

    Peripheral Interfaces

    IO

    • 1x PCIe Gen3 2-Lane 1x PCIe Gen2 1-Lane (share with 1x USB3.1) 2x USB 3.1 (Host) 2x USB 2.0 (Host/Device) 1x Giga Ethernet MAC 1x SD/SHDC/MMC and SDIO3.0/3.0 6xUART, 6xSPI, 6xI2C, 4xPWM, 2x I2S for Audio

    Wireless Connectivity

    Wi-Fi/Bluetooth

    • Up to Wi-Fi 6, BT 5.2
    • Enabled via PCIe or USB 2.0 interface

    Camera

    ISP

    • Internal ISP
    • 48MP @ 30fps
    • 16MP+16MP @ 30fps
    • 3x MIPI CSI-2 4-Lane

    Package

    Type/Size

    • MFC VFBGA, 15*15*0.9mm
