MediaTek
Dimensity 7200
MediaTek Dimensity
Flagship 5G Family
MediaTek Dimensity 7200
at-a-glance
MediaTek Dimensity 7200
Introducing powerful 2nd generation Armv9 CPUs, impressive power efficiency, and MediaTek HyperEngine 5.0 to incredible 5G smartphones for everyone. Get your hands on high-end AI-camera technologies and benefit from 14-bit HDR imaging that gives impressive captures, day or night.
Best-in-class Power Efficiency
Embracing flagship-class power efficiency of TSMC’s 2nd-Gen 4nm chip production process, the MediaTek Dimensity 7200 integrates high-end technologies, introducing 2nd generation Armv9 processors with a fast peak performance of up to 2.8GHz, ensuring effortless multitasking, great gaming performance, and a strong generational performance uplift, while also maximizing battery life.
Additional Key Features
MediaTek HyperEngine 5.0 provides a comprehensive suite of gaming-related optimizations for the whole smartphone, including optimized 5G and Wi-Fi game connections, exclusive AI-VRS for power savings, CPU & GPU smart resource optimization, low-latency wireless earbuds with Bluetooth LE Audio technology with Dual-Link True Wireless Stereo Audio, and more. Additionally, the Arm Mali G610 MC4 GPU ensures smooth, high frame rates in popular games.
The built-in MediaTek NPU 650 maximizes task efficiency of AI tasks and AI-fusion processing, unlocking new opportunities for device makers to provide new experiences, enhanced visuals, improved power efficiency, and upgraded performance.
MediaTek Imagiq 765 premium-grade 14-bit HDR-ISP supports 200MP main cameras for epic photography. Record either 4K HDR video, or simultaneously from two cameras at Full HD resolution, while keeping everything in focus with all-pixel autofocus.
Captures at night or in low-light situations benefit from motion compensated noise reduction (MCNR) ensuring videos and livestreams are always crisp and clear. With the MediaTek NPU 650, powerful AI-Camera enhancements such as real-time portrait beautification are available.
MediaTek MiraVision 765 supports global HDR standards - HDR10+, CUVA HDR, Dolby HDR - for media streaming and playback. AI SDR-to-HDR video playback intelligently upgrades standard media to HDR visuals, providing a superior experience.
The 3GPP Release-16 standard 5G modem provides extremely fast downlink performance up to 4.7Gbps. Dual 5G SIM with dual VoNR gives users more choice, premium voice and video call quality, and can support work and personal connections from a single smartphone. The combination of a fully integrated 5G modem and MediaTek 5G UltraSave 2.0 technology suite ensures best-in-class cellular power efficiency, extending battery life.
Tri-band Wi-Fi 6E with 2x2 antenna provides supremely fast wireless networking with upgraded connection reliability. When using BT earbuds/peripherals and Wi-Fi together, MediaTek Wi-Fi/Bluetooth hybrid coexistence technologies ensure they work together seamlessly with the lowest latency.
Specifications
Processor
CPU
- 2x Arm Cortex-A715 up to 2.8GHz
- 6x Arm Cortex-A510
Cores
Octa (8)
Memory & Storage
Memory Type
- LPDDR4x
- LPDDR5
Max Memory Frequency
Up to 6400Mbps
Storage Type
UFS 3.1
Connectivity
Cellular Technologies
2G-5G Multi-Mode, 5G/4G CA, 5G/4G FDD / TDD, CDMA2000 1x/EVDO Rev. A (SRLTE), EDGE, GSM, TD-SCDMA, WDCDMA
Specific Functions
SA & NSA modes; SA Option2, NSA Option3 / 3a / 3x, NR TDD and FDD bands, DSS, NR DL 2CC 200MHz bandwidth, 4x4 MIMO, 256QAM NR UL 2CC, R16 UL Enhancement, 2x2 MIMO, 256QAM VoNR / EPS fallback
Peak Downlink Speed
4.7Gbps
GNSS
- GPS
- BeiDou
- Glonass
- Galileo
- QZSS
- NavIC
Wi-Fi
Wi-Fi 6E (a/b/g/n/ac/ax)
Wi-Fi Antenna
2T2R
Bluetooth
5.3
Camera
Max Camera Sensor
200MP
Max Video Capture Resolution
4K (3840 x 2160)
Camera Features
- Video HDR
- Video EIS
- Dual simultaneous video capture
- AI-2A (AI-AF, AI-AWB)
- All-pixel AF
Graphics
GPU Type
Arm Mali-G610 MC4
Video Encoding
- H.264
- HEVC
Video Playback
- H.264
- HEVC
- VP-9
Display
Max Refresh Rate
Full HD+ @ 144Hz
AI
MediaTek 5th generation NPU
NPU 650
